High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38

Name: High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38
Brand: Shanghai Fanying Machinery Technology Co., Ltd.
SKU: FY-P38
Price: 1,350.00 USD
Availability: InStock

Brand Name:	FY
Model Number:	FY-P38
MOQ:	1 set
Price:	USD$ 1600/1500/1400/1300
Payment Terms:	L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability:	300 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China,Shanghai

Certification:

Voltage:

220V/240V/380V/415V(Optional)

Gross Weight:

300kgs

Net Weight:

275kg

Power(w):

3KW/4KW

Dimension(l*w*h):

950*630*700 Mm

Package Dimension:

1000*680*750 Mm

Warranty:

1 Year

Condition:

New

After-sales Service Provided:

Video Technical Support,Online Support

Crimping Force:

300Ton

Product Name:

CE Approved 6-51mm High Pressure Hydraulic Hose Crimping Machine

Crimping Range:

6-38mm

Color:

Blue,blue Or Customize

Application:

Crimp Hose

Free Dies:

8sets

System Pressure:

26MPA/31.5MPA

Output Volume Of Pump:

2.5L/5L

HIGH LIGHT:

Advanced Hydraulic Pipe Crimping Machine, Dash Control Hydraulic Pipe Crimping Machine, Pipe Crimping Machine

Packaging Details:

wooden box

Supply Ability:

300 sets per month

Highlight:

high pressure hydraulic hose crimping machine 38mm

hose crimping machine quick opening

hose crimping machine p38

Product Description

38mm Hydraulic Hose Crimping Machine P38 Quick Opening Hydraulic Hose Crimper

DESCRIPTION

Install the metal jacket of the joint, and then put the joint iron core into the inner hole of the hose.FY-P38 high pressure hose crimper is with crimping ability from 6mm to 38mm (1/4'' to 1.5'') for high pressure hydraulic hose. It is with quick change tool for die sets and die rack, which support a safe place for dies.

THE MACHINE'S EXCELLENT MAIN FEATURES
1) Famous Brand valve system, high quality, long using time, low maintenance cost
2) Foot pedal frees the operator's hand for holding big size hydraulic hose
3) Advanced Dash control, multifunction for crimping work
4) Quick change for die sets enable die sets change all at one time

crimping range	6-38mm(1/4''-1.5''inner diameter of hose)
Rated pressure	26Mpa/31.5Mpa(Optional)
The largest crimping pressure	300T
Rular precision	0.01mm
Output volume of pump	2.5L/5L(Optional)
Net weight	275kg
Work efficiency	200pcs/h
size	950630700 mm
dies	8 sets
Item No.of dies	length 60mm(15,19,23,26);Length 70mm(31,36,41);Length 80mm(47,55,60)

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 0

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 1

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 2

TECHNICAL DATA

Model	FY-P38 Hose Crimping Machine
Crimping Range	6-38(mm)
Crimping Force	300(T)
Hose Size	1/4-1.5(inch)
Max. Opening	20±mm
Die Sets	8
Maximum Open Diameter	104MM
System Pressure	26(Mpa)/31.5(Mpa)
Accuracy	0.01(mm)
Work Efficiency	200 pcs/h
Standard Voltage	220v/240v/380v/415v(optional)
Motor Power	3(KW)/4(KW)
Length	950(mm)
Width	630(mm)
Height	700(mm)
Weight	275(KG)

NOTE

- for non standard die sets;

- Customized die sets are available;

- Special voltage 220V, 240V, 380V,415V are availbale;

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 3

crimping range	6-38mm(1/4''-1.5''inner diameter of hose)
Rated pressure	26Mpa/31.5Mpa(Optional)
The largest crimping pressure	300T
Rular precision	0.01mm
Output volume of pump	2.5L/5L(Optional)
Net weight	275kg
Work efficiency	200pcs/h
size	950630700 mm
dies	8 sets
Item No.of dies	length 60mm(15,19,23,26);Length 70mm(31,36,41);Length 80mm(47,55,60)

► ADVANCED PLC SYSTEM
Multifucntional control panel with different operation mode

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 4

► DIE SETS
8 die sets hardness 59-63HRC, with quick change tool, productivity improve much.

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 5

► FAMOUS BRAND MOTOR
World famous motor with high stability

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 6

► ONE PIECE FORGED OIL CYLINDER
Forged cylinder has higher anti wear ability compared with traditional technology

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 7

► APPLICATIONS
FY-P38 is a high configured hose crimper, it has the ability of crimping high pressure stainless steel braided hydraulic oil hose, industrial fexible pipes, air or water hose, cable and wires, steel and iron tubes, brake lines in automotive system, air suspension or springs.

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 8

High Pressure Hydraulic Hose Crimping Machine 38mm Quick Opening P38 9
