12v 24v Automatic Hose Crimping Machine Battery Drive 2" Hydraulic Hose Crimper
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xReinforcement | 1-4 Layers Wire | Crimping Range | 6-51 Mm |
---|---|---|---|
Quantity Of Dies | 10 Sets | Accuracy | 0.01 Mm |
System Pressure | 30mpa | Motor Power | 3.6kw |
Voltage | 12v/24v(optional) | Crimping Force | 600t |
HIGH LIGHT | Car 12V Hydraulic Hose Crimper, High Configuration 12V Hydraulic Hose Crimper, 24V Hose Crimping Machine | ||
High Light | 12v automatic hose crimping machine,24v automatic hose crimping machine,2" hydraulic hose crimper |
crimping range | 6-51 mm | |
---|---|---|
quantity of dies | 10 sets | |
accuracy | 0.01 mm | |
output volume of pump | 4L | |
system pressure | 30mpa | |
motor power | 3.6kw | |
voltage | 12v/24v(optional) | |
crimping force | 600 t | |
work efficiency | 200 pcs/h | |
maximum open diameter | 114 mm | |
the max open tolerance | 30 ±mm | |
machine dimension | 650*600*600 mm | |
package dimension | 750*700*700 mm | |
net weight | 170 kg | |
gross weight | 180 kg | |
2 Inch Hose Crimping Machine Battery Drive 24V 12v Hydraulic Hose Crimper
DESCRIPTION
FY-51CZ hose crimping machine
Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
THE MACHINE'S EXCELLENT FEATURES:
► Use the 12V/24V battery as a power, crimping force can be reach 2800 KN
► The stable quality crimping performance find expression in high pressure
► The most popular applications for these suitable are in repair shop and industrial maintenance unit
TECHNICAL DATA
Model | FY-51CZ Pipe Crimping Machine |
Crimping Range | 6-51(mm) |
Crimping Force | 600(T) |
Hose Size | 1/4-2(inch) |
Max. Opening | 114(mm) |
Die Sets | 10 |
output volume of pump
|
4L |
System Pressure | 30(Mpa) |
Accuracy | 0.01(mm) |
the max open tolerance
|
30 ±mm
|
Standard Voltage | 12V/24(V) |
Motor Power | 3.6(KW) |
Length | 650(mm) |
Width | 600(mm) |
Height | 600(mm) |
Weight | 170(KG) |
NOTE
• " * " for non standard die sets
• Customized die sets with different shape size ia available
• Voltage 12V/24V is available
OPTIONAL
• Quick Change Tool
• Quick Change Die Set Rack
• Car installing unit
► FORGED CYLINDER
One piece structure, prevent oil leackage problem, save oil transfer time, increase productivity
► MICROMETER
FY51CZ is with high accuracy dial, 0.01mm.
► DIE SET REFERENCE SHEET
This sheet tells you how to choose proper die set for different crimping size
► WIDE USAGE
FY-51CZ Crimping machine can be used in a mobile van which can supply 12V/24V power.
For high pressure oil rubber hose assmbly crimping, low pressure water or air hose pressing, steel tube
swaging, wire rope pressing, lock device making, etc.
