| Brand Name: | FY |
| Model Number: | FY-51BJ-1L |
| MOQ: | 1 set |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 sets per month |
Easy To Operate rubber hose pipe peeler machine/hose skiving machine/skiving tool
DESCRIPTION
1.The skiving machine is highly automatic, with a neat, efficient skiving performance.
2.Automatic hose skiving machine is equipped with a reducer to stabilize the speed.
3.For the sake of safety, the machine will automatically cease operation if the protective cover is removed.
FY-51BJ-1L is a hose cutting/skiving machine which also have the ability to strip hose rubber.
hydraulic hose skiving machine includes motor,reducer,electrical box,frame,cage,edge rod support,edge rod,mandrels,mandrel box and pedal.
The advantages of our different hydraulic hose peeler/skiving machine and our company
1.Have quality guarantee and enjoy high reputation in global market
2.Rich experience and focus on machines manufacturing for many years
3.Strictly processed control and advanced management
4.Best service and competitive price.
5.Having various hydraulic hose and hose crimping machines with different types and models
6.Perfect equipment and Superior technology.
7.Meet international standard and passed the ISO9001:2000 certificate.
ADVANTAGES
1. Movable wheel to make the machine more convenient to move;
2. Human design handle, save opetator power;
3. Scale on the skiving tool, easy to adjust the skiving depth;
4. High quality copper wire aluminium motor, no heat exceed even afetr using for a long time.
TECHNICAL DATA
| Model | FY-51BJ-1L Hose Cutting/skiving Machine |
| Hose Size | 1/4''-2'' |
| Work Efficiency | 1500pcs/h |
| Voltage | 220v-415v 50/60hz(optional) |
| Motor Power | 0.75-1.5kw |
|
Accuracy
|
manual |
| Quality Of Dies | 10 pcs |
| Length | 620mm |
| Width | 470mm |
| Height | 1050mm |
| Weight |
75kg |
