| Brand Name: | FanYing |
| Model Number: | FY-NBR70/80/90 |
| MOQ: | 1000 pieces |
| Price: | USD$ 0.58 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300000 PIECES PER DAY |
Rubber O Rings are a type of sealing ring designed to withstand high pressure and extreme conditions. They are commonly used in hydraulic and pneumatic systems, as well as in a variety of industrial and automotive applications.
Rubber O Rings are made from high-quality materials, such as Nitrile Rubber, FKM, and WF-ring, and are designed to meet the demands of high-pressure environments. These rings come in a variety of sizes and shapes to fit different sealing needs. The O-shaped design provides a tight seal between two surfaces, preventing leaks and ensuring the smooth operation of the system.
Rubber O Rings have a pressure range of up to 5,000 Psi, making them ideal for high-pressure applications. They can withstand extreme levels of pressure without deforming or losing their sealing capabilities, ensuring the safety and efficiency of the system.
Our Rubber O Rings are processed through mold opening, ensuring precision and consistency in their size and shape. This process also allows for customization, making it possible to create O Rings in unique sizes and designs to meet specific sealing needs.
These O Rings have a working pressure of ≤40 Mpa, making them suitable for a wide range of industrial and automotive applications. They can effectively seal hydraulic and pneumatic systems, as well as other high-pressure systems, ensuring smooth and efficient operation.
Rubber O Rings have excellent oil resistance, making them suitable for use in machinery and equipment that come in contact with oils and other petroleum-based fluids. They can withstand the harsh effects of oils and maintain their sealing capabilities for extended periods, ensuring the longevity of the system.
We offer samples of our Rubber O Rings for customers to test and evaluate before making a bulk purchase. The samples are shipped on a freight collect basis, making it cost-effective for customers to try out our products.
In conclusion, Rubber O Rings are the ultimate solution for high-pressure applications. With their high pressure range, mold opening processing services, excellent working pressure, oil resistance, and convenient sample options, these rings provide a reliable and efficient sealing solution for a variety of industries and applications. Choose Rubber O Rings for your high-pressure needs and experience their superior sealing capabilities.
The allowable dimension deviation of NBR O-ring of 70 Shore A is shown in the table below:
| ID± Tolerance | W± Tolerance | ||||
| -3 | 0.14 | 120-150 | 1.2 | -1.8 | 0.08 |
| 3-6 | 0.15 | 150-180 | 1.4 | 1.8-2.6 | 0.09 |
| 6-10 | 0.17 | 180-250 | 1.8 | 2.6-3.5 | 0.10 |
| 10-18 | 0.20 | 250-300 | 2.1 | 3.5-5.3 | 0.13 |
| 18-30 | 0.30 | 300-350 | 2.5 | 5.3-7 | 0.15 |
| 30-50 | 0.40 | 350-400 | 2.8 | 7-8 | 0.17 |
| 50-80 | 0.65 | 400-500 | 3.4 | 8-10 | 0.20 |
| 80-100 | 0.85 | 500-650 | 4.3 | 10-15 | 0.25 |
| 100-120 | 1.00 | 650-800 | 6.5 | ||
| Product Name | Rubber O Rings |
|---|---|
| Warranty | 12 Months |
| Using | Oil Gas Field Sealing |
| Oil Resistance | Good |
| Port | Shanghai |
| Tear Strength | 16-30 N/mm |
| Pressure Range | Up To 5,000 Psi |
| Working Pressure | ≤40 Mpa |
| Standard | AS568, P, G, S |
| Packing | Cartoon Bag |
| Sample | Freight Collect |
| Material | Nitrile Rubber, FKM (Fluorocarbon Rubber) |
| Product Type | FKM Wall Sealing Rings |
| Application | Oil and Gas Industry |
Are you looking for a reliable and durable sealing solution for your oil and gas fields? Look no further, FanYing's Rubber O Rings are here to meet all your needs. With our high-quality FKM rubber seal and WF-ring technology, our O rings are designed to provide the best sealing performance under extreme pressure and temperature conditions.
Model Number: FY-NBR70/80/90
Place of Origin: China
Pressure Range: Up To 5,000 Psi
Port: Shanghai
FanYing's Rubber O Rings are made with high-quality FKM (Fluorocarbon Rubber) material, which is known for its excellent oil resistance, high temperature resistance, and corrosion resistance. This makes our O rings ideal for use in the oil and gas industry, where they are exposed to harsh chemicals, extreme temperatures, and high pressures.
Our Rubber O Rings are widely used in the oil and gas fields for various sealing applications, including:
These O rings are suitable for both onshore and offshore operations, making them a versatile sealing solution for all your oil and gas field needs.
Our Rubber O Rings are designed to withstand a working pressure of ≤40 Mpa, making them suitable for use in high-pressure environments. They are manufactured according to the AS568, P, G, and S standards, ensuring their compatibility with various industrial applications.
With FanYing's Rubber O Rings, you can ensure a leak-free and efficient operation of your oil and gas fields.
At FanYing, we offer top-quality custom rubber o rings for a variety of industrial applications. Our WF seals are made with high-grade FKM WF rings, also known as FKM rings, to ensure durability and reliability.
Our o rings are designed specifically for use in oil and gas field sealing, making them ideal for harsh environments and high-pressure systems. With our custom services, we can tailor the size, shape, and material of our o rings to meet your specific needs.
Whether you require OEM or ODM services, we are fully equipped to accommodate your customization requests. Our skilled team can provide mold opening services to create unique o ring designs that meet your exact specifications.
Choose FanYing for superior quality, customizable rubber o rings that can withstand even the most demanding applications. Contact us today to learn more about our products and services.
Our Rubber O Rings are carefully packaged to ensure their safe delivery to our customers. Each pack contains a set of O Rings, and the number of O Rings in each pack varies depending on the size and type of O Rings ordered.
The O Rings are first placed in a plastic bag to protect them from any external elements. The bag is then sealed to prevent any damage during shipping.
The O Rings are then packed in a sturdy cardboard box, which is further reinforced with bubble wrap or foam inserts to provide additional protection during transportation.
The box is then sealed and labeled with the product name, size, and quantity to ensure easy identification upon delivery.
We offer various shipping options to our customers, including standard shipping, express shipping, and international shipping.
For standard shipping, we use reliable courier services to deliver the package within the estimated time frame. Customers can track their orders through a tracking number provided by us.
For express shipping, we use expedited services to ensure faster delivery for urgent orders. However, this option may incur additional charges.
For international shipping, we follow all necessary customs regulations and provide all required documentation for smooth delivery of the package.
We take great care in packaging our Rubber O Rings to prevent any damage during shipping. However, in case of any unforeseen circumstances, we offer a return and refund policy for our customers' satisfaction.
A: The material of Rubber O Rings is NBR (Nitrile Butadiene Rubber).
A: The temperature range for using Rubber O Rings is -40°C to 120°C.
A: Yes, Rubber O Rings are highly resistant to oil and other petroleum-based fluids.
A: Yes, Rubber O Rings are suitable for sealing water and other non-corrosive fluids.
A: The size of Rubber O Rings is determined by the inner diameter, outer diameter, and cross-sectional diameter. You can refer to the size chart provided by FanYing or contact us for assistance.
