| Brand Name: | FanYing |
| Model Number: | FY-NBR70/80/90 |
| MOQ: | 1000 pieces |
| Price: | USD$ 0.8 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300000 PIECES PER DAY |
Rubber O Rings are a type of seal ring used in various industries, such as automotive, machinery, and aerospace. They are designed to provide a tight and reliable seal between two or more parts, preventing leakage of fluids or gases.
These O Rings are made from high-quality rubber materials, such as FKM WF and NBR, which offer excellent resistance to oil and other chemicals. This makes them suitable for use in a wide range of applications, including those involving harsh environments and high temperatures.
Our Rubber O Rings are available in a variety of sizes to meet the demands of our clients. We can provide sizes ranging from C/s to meet the specific requirements of your project.
To ensure the safe and convenient transportation of our products, we pack our Rubber O Rings in high-quality cartoon bags. This not only protects the rings from damage but also makes it easy to store and handle them.
We understand that every project has unique requirements, and that's why we offer customization options for our Rubber O Rings. We can provide OEM and ODM services to meet your specific needs and ensure the perfect fit for your application.
Our Rubber O Rings are specially designed to have excellent oil resistance. This means they can withstand exposure to various oils and lubricants without deteriorating, making them ideal for use in machinery and automotive applications.
Our Rubber O Rings meet the highest standards of quality and durability. They are manufactured according to AS568 standards and are also available in P, G, and S sizes.
Our FKM WF Rings are made from the highest quality FKM (fluorocarbon) rubber, which offers superior resistance to chemicals, heat, and oils. This makes them suitable for use in demanding applications, such as in the aerospace industry.
Our Rubber O Rings provide effective sealing for wall joints and connections. The FKM material used in these rings ensures a tight and reliable seal, minimizing the risk of leaks and improving overall performance.
NBR O Rings are made from nitrile rubber, which offers excellent resistance to oils, fuels, and other chemicals. These rings are commonly used in hydraulic and pneumatic systems, as well as in automotive and industrial applications.
In conclusion, our Rubber O Rings are a versatile and reliable solution for sealing applications. With a wide range of sizes, customization options, and high-quality materials, they are the perfect choice for your sealing needs.
The allowable dimension deviation of NBR O-ring of 70 Shore A is shown in the table below:
|
ID± Tolerance |
W± Tolerance |
||||
| -3 | 0.14 | 120-150 | 1.2 | -1.8 | 0.08 |
| 3-6 | 0.15 | 150-180 | 1.4 | 1.8-2.6 | 0.09 |
| 6-10 | 0.17 | 180-250 | 1.8 | 2.6-3.5 | 0.10 |
| 10-18 | 0.20 | 250-300 | 2.1 | 3.5-5.3 | 0.13 |
| 18-30 | 0.30 | 300-350 | 2.5 | 5.3-7 | 0.15 |
| 30-50 | 0.40 | 350-400 | 2.8 | 7-8 | 0.17 |
| 50-80 | 0.65 | 400-500 | 3.4 | 8-10 | 0.20 |
| 80-100 | 0.85 | 500-650 | 4.3 | 10-15 | 0.25 |
| 100-120 | 1.00 | 650-800 | 6.5 | ||
| Technology | Compression Molding |
|---|---|
| Sample | Freight Collect |
| Using | Oil Gas Field Sealing |
| Processing Services | Mold Opening |
| Pressure Range | Up To 5,000 Psi |
| Packing | Cartoon Bag |
| Oil Resistance | Good |
| Avilable Size | C/s Depend On Client Demand |
| Tear Strength | 16-30 N/mm |
| Standard | AS568 , P, G, S |
| Key Features | FKM rings, WF seals, Nitrile Rubber Ring |
Brand Name: FanYing
Model Number: FY-NBR70/80/90
Place of Origin: China
Technology: Compression Molding
Working Pressure: ≤40 Mpa
Sample: Freight Collect
Tear Strength: 16-30 N/mm
Custom: Available OEM/ODM
Nitrile Rubber Ring, FKM rings, FKM rings manufacturers, O-ring, sealing rings, rubber products, sealing solutions
Product Description:
Rubber O Rings, also known as sealing rings, are circular rings made of nitrile rubber or FKM, designed to provide an effective and reliable sealing solution for various industrial applications. These rings are manufactured by FanYing, a leading brand in the rubber products industry, using advanced compression molding technology in their production process.
Application:
The Rubber O Rings from FanYing can be used in a wide range of industries and applications, including but not limited to:
Features and Benefits:
Why Choose FanYing Rubber O Rings?
For all your sealing needs, choose FanYing Rubber O Rings for a reliable and efficient solution. Contact us today for more information and to request a quote.
Brand Name: FanYing
Model Number: FY-NBR70/80/90
Place of Origin: China
Using: Oil Gas Field Sealing
Sample: Freight Collect
Working Pressure: ≤40 Mpa
Packing: Cartoon Bag
Standard: AS568, P, G, S
Key Features: WF rings, FKM rings, FKM rings
