| Brand Name: | FanYing |
| Model Number: | FY-NBR70/80/90 |
| MOQ: | 1000 pieces |
| Price: | USD$ 0.48 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300000 PIECES PER DAY |
Our Rubber O Rings are specially designed to provide reliable sealing in the most demanding environments of the oil and gas industry. Made from high-quality FKM and Nitrile rubber, these O rings are built to withstand extreme pressures and harsh chemicals, ensuring the safety and efficiency of your operations.
When it comes to high-pressure sealing in the oil and gas industry, our Rubber O Rings stand out for their exceptional performance and durability. Here are some of the key reasons why you should choose our product:
Don't compromise on the quality and reliability of your high-pressure sealing needs. Choose our Rubber O Rings and experience superior performance and durability. Contact us today to learn more or to place your order.
The allowable dimension deviation of NBR O-ring of 70 Shore A is shown in the table below:
|
ID± Tolerance |
W± Tolerance |
||||
| -3 | 0.14 | 120-150 | 1.2 | -1.8 | 0.08 |
| 3-6 | 0.15 | 150-180 | 1.4 | 1.8-2.6 | 0.09 |
| 6-10 | 0.17 | 180-250 | 1.8 | 2.6-3.5 | 0.10 |
| 10-18 | 0.20 | 250-300 | 2.1 | 3.5-5.3 | 0.13 |
| 18-30 | 0.30 | 300-350 | 2.5 | 5.3-7 | 0.15 |
| 30-50 | 0.40 | 350-400 | 2.8 | 7-8 | 0.17 |
| 50-80 | 0.65 | 400-500 | 3.4 | 8-10 | 0.20 |
| 80-100 | 0.85 | 500-650 | 4.3 | 10-15 | 0.25 |
| 100-120 | 1.00 | 650-800 | 6.5 | ||
| Specification | Value |
|---|---|
| Standard | AS568, P, G, S |
| Custom | Available OEM/ODM |
| Technology | Compression Molding |
| Working Pressure | ≤40 Mpa |
| Pressure Range | Up To 5,000 Psi |
| Packing | Cartoon Bag |
| Available Size | C/s Depend On Client Demand |
| Oil Resistance | Good |
| Processing Services | Mold Opening |
| Using | Oil Gas Field Sealing |
| FKM Rubber Seal | |
| FKM Rubber Seal | |
| FKM Wall Sealing |
FanYing Rubber O Rings are high-quality and durable sealing rings designed specifically for use in the oil and gas field. These O rings are made of FKM, also known as FKM or FPM, which is a synthetic rubber material with excellent resistance to heat, chemicals, and oils. The brand name FanYing stands for reliability and performance, making it the top choice for companies in the oil and gas industry.
The Model Number for these O rings is FY-NBR70/80/90, indicating the different levels of hardness and chemical resistance available. These O rings are manufactured in China, ensuring top-quality materials and production processes. They are tested for tear strength, with a range of 16-30 N/mm, making them suitable for use in high-pressure and high-temperature environments.
One of the key applications for FanYing Rubber O Rings is in oil and gas field sealing. These O rings provide an effective and reliable seal, preventing leaks and maintaining the integrity of equipment and pipelines. They are also suitable for use in a wide range of other industrial and commercial applications, where resistance to heat, chemicals, and oils is essential.
FanYing Rubber O Rings are available in a range of standard sizes, including AS568, P, G, and S. These sizes are commonly used in the oil and gas industry, making it easier for companies to find the right O rings for their equipment. However, custom sizes are also available to meet the specific demands of clients. This flexibility makes FanYing Rubber O Rings a highly versatile and customizable product.
In addition to standard and custom sizes, FanYing also offers OEM and ODM services. This means that companies can customize the design and branding of the O rings to suit their specific needs. This is particularly useful for companies with unique equipment or branding requirements, as it allows them to maintain consistency and brand recognition.
Overall, FanYing Rubber O Rings are a top choice for companies in the oil and gas industry, as well as other industrial and commercial applications. Their high-quality materials, tear strength, and customizable options make them a reliable and versatile sealing solution. Choose FanYing for your next project and experience the best in FKM rings.
Brand Name: FanYing
Model Number: FY-NBR70/80/90
Place of Origin: China
Custom: Available OEM/ODM
Using: Oil Gas Field Sealing
Available Size: C/s Depend On Client Demand
Tear Strength: 16-30 N/mm
Working Pressure: ≤40 Mpa
Key Words: WF seals, WF-ring, FKM Rubber Seal, NBR Oil Seal
Rubber O Rings are carefully packaged to ensure safe delivery to our customers. Each package is tailored to protect the o rings from damage during shipping.
We offer various shipping options to meet our customers' needs:
Once the order is shipped, customers will receive a tracking number to monitor the status of their delivery.
At Rubber O Rings, we take great care in packaging and shipping our products to ensure they arrive in perfect condition. Customer satisfaction is our top priority.
