| Brand Name: | FanYing |
| Model Number: | FY-NBR70/80/90 |
| MOQ: | 1000 pieces |
| Price: | USD$ 0.48 |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 300000 PIECES PER DAY |
Rubber O Rings are essential components in many industrial applications, providing reliable sealing and protection against leakage. Our Rubber O Rings are made from high quality FKM (fluorocarbon rubber) material, ensuring superior performance and durability.
Our Rubber O Rings are available in standard sizes: AS568, P, G, S, and can be customized according to client's demands. They are packed in a convenient cartoon bag for easy storage and transportation.
One of the key features of our Rubber O Rings is its excellent oil resistance. This makes them ideal for use in applications where exposure to oils and fuels is common. The FKM material used in our O Rings also provides good tear strength, with a range of 16-30 N/mm, ensuring long-lasting performance.
In addition to its oil resistance, our Rubber O Rings also offer other important properties such as incompressibility, temperature resistance, and corrosion resistance. These features make them suitable for use in various industrial environments, including those with high pressure and extreme temperatures.
Our Rubber O Rings are also compatible with Walform and WF seals, providing a reliable sealing solution for a wide range of applications. With their high quality and versatility, our Rubber O Rings are the top choice for FKM wall sealing in industrial settings.
Choose our Rubber O Rings for your industrial sealing needs, and experience the superior performance and durability that our products offer. Contact us today to discuss your specific requirements and availabilities in C/s sizes.
The allowable dimension deviation of NBR O-ring of 70 Shore A is shown in the table below:
|
ID± Tolerance |
W± Tolerance |
||||
| -3 | 0.14 | 120-150 | 1.2 | -1.8 | 0.08 |
| 3-6 | 0.15 | 150-180 | 1.4 | 1.8-2.6 | 0.09 |
| 6-10 | 0.17 | 180-250 | 1.8 | 2.6-3.5 | 0.10 |
| 10-18 | 0.20 | 250-300 | 2.1 | 3.5-5.3 | 0.13 |
| 18-30 | 0.30 | 300-350 | 2.5 | 5.3-7 | 0.15 |
| 30-50 | 0.40 | 350-400 | 2.8 | 7-8 | 0.17 |
| 50-80 | 0.65 | 400-500 | 3.4 | 8-10 | 0.20 |
| 80-100 | 0.85 | 500-650 | 4.3 | 10-15 | 0.25 |
| 100-120 | 1.00 | 650-800 | 6.5 | ||
| Product Name | Rubber O Rings |
|---|---|
| Material | Nitrile Rubber Ring, FKM Rubber Seal |
| Oil Resistance | Good |
| Pressure Range | Up To 5,000 Psi |
| Custom | Available OEM/ODM |
| Processing Services | Mold Opening |
| Technology | Compression Molding |
| Sample | Freight Collect |
| Using | Oil Gas Field Sealing |
| Available Size | C/s Depend On Client Demand |
| Packing | Cartoon Bag |
| Standard | AS568, P, G, S |
| Other Names | WF-ring |
Model Number: FY-NBR70/80/90
Place of Origin: China
Sample: Freight Collect
Tear Strength: 16-30 N/mm
Packing: Cartoon Bag
Pressure Range: Up To 5,000 Psi
Using: Oil Gas Field Sealing
FanYing's Rubber O Rings are specially designed for high pressure sealing in the oil and gas industry. Made from FKM rubber seal and nitrile rubber ring, these O rings are durable, reliable, and cost-effective for various applications.
Brand Name: FanYing
Model Number: FY-NBR70/80/90
Place of Origin: China
Oil Resistance: Good
Tear Strength: 16-30 N/mm
Pressure Range: Up To 5,000 Psi
Using: Oil Gas Field Sealing
Working Pressure: ≤40 Mpa
FanYing Rubber O Rings, also known as WF rings, are the ideal choice for oil and gas field sealing. With our customized service, you can be sure to find the perfect solution for your specific sealing requirements.
At WF Seals, we take pride in our partnership with FanYing as our trusted brand for rubber O rings. With their high quality and durability, you can be assured of top-notch performance in any application.
Our FY-NBR70/80/90 O rings are specifically designed for oil and gas field sealing. With good oil resistance and tear strength ranging from 16-30 N/mm, they can withstand harsh environments and ensure reliable sealing performance.
At WF Seals, we understand that every sealing application is unique. That's why we offer customized service to cater to your specific needs. Our team of experts will work closely with you to provide the best solution for your sealing requirements.
In addition to our FanYing O rings, we also offer FKM rubber seals for high-pressure sealing needs. With a pressure range of up to 5,000 Psi and working pressure of ≤40 Mpa, they are the perfect choice for demanding sealing applications.
Choose WF Seals for all your rubber O ring needs and experience our top-notch customized service. Contact us today to learn more.
Our Rubber O Rings are carefully packaged to ensure their quality and protection during shipping. They are packed in a sturdy and durable box, with each ring individually wrapped in plastic to prevent any damage or contamination.
In order to meet the different needs of our customers, we also offer customized packaging options. Please contact us for more information.
We offer various shipping options to ensure timely delivery of our Rubber O Rings:
For bulk orders, we provide special shipping arrangements and discounts. Please contact us for more details.
Our team takes great care in packaging and shipping our Rubber O Rings to ensure they arrive in perfect condition. However, in the rare case of any damage during shipping, please contact us immediately and we will work to resolve the issue.
