3kw 4kw High Pressure Hose Crimping Machine Hydraulic DX68 Different Colour 2 Inch
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xVoltage | 220V/240V/380V/415V(Optional) | Gross Weight | 260kgs |
---|---|---|---|
Net Weight | 245kg | Power(w) | 3KW/4KW |
Dimension(l*w*h) | 730*480*740 Mm | Package Dimension | 800*530*870 Mm |
Warranty | 1 Year | Condition | New |
After-sales Service Provided | Video Technical Support,Online Support | Crimping Force | 600Ton |
Product Name | CE Approved 6-51mm High Pressure Hydraulic Hose Crimping Machine | Crimping Range | 6-51mm |
Color | Blue,blue Or Customize | Application | Crimp Hose |
Free Dies | 10sets | System Pressure | 31.5MPA |
Output Volume Of Pump | 2.5L/5L/10L | ||
High Light | 3kw high pressure hose crimping machine,4kw high pressure hose crimping machine,high pressure hydraulic hose crimper dx68 |
crimping range | 6-51 mm | |
---|---|---|
quantity of dies | 10 sets | |
accuracy | 0.01 mm | |
output volume of pump | 2.5L/5L/10L | |
system pressure | 31.5mpa | |
motor power | 3kw/4kw | |
voltage | 220v/240v/380v/415v (optional) | |
crimping force | 600 t | |
work efficiency | 200 pcs/h | |
maximum open diameter | 114 mm | |
the max open tolerance | 30 ±mm | |
machine dimension | 730*480*740 mm | |
package dimension | 800*530*870 mm | |
net weight | 245 kg | |
gross weight | 260 kg |
Different Colour 2 inch 3KW/4KW DX68 Hose Crimping Machine
DESCRIPTION
Button Control Panel, Manual or Automatic Mode
The buttons are on the left side, convenient to control the whole crimping work and see the whole crimping progress.
FY-DX68 is a hot sale domestic design hose crimping machine based on DX68 series. It provide 600T crimping force, can be worked automatically or manually depends on different need. The hose crimping machine is offered with wheels, easy for move. With a foot pedal can make the hand free during crimping.
MAIN FEATURES
1. Forged crimping clylinder, high hardness;
2. Multifunctional operate panel, two operate mode;
3. Pressure Gauge, system shown clearly during crimping;
4. Foot pedal as standard to make hands free;
5. Working light to make crimping work more clear.
TECHNICAL DATA
Model | FY-DX68 Hose Crimping Machine |
Crimping Range | 6-51(mm) |
Crimping Force | 600(T) |
Hose Size | 1/4-2(inch) |
Max. Opening | 30mm |
Die Sets | 10 |
Maximum Open Diameter |
114MM |
System Pressure | 31.5(Mpa) |
Accuracy | 0.01(mm) |
Work Efficiency |
200 pcs/h |
Standard Voltage | 220(V)/380(V) |
Motor Power | 3(KW)/4(KW0 |
Length | 730(mm) |
Width | 480(mm) |
Height | 740(mm) |
Weight | 245(KG) |
NOTE
- for non standard die sets;
- Customized die sets are available;
- Special voltage 220V, 240V, 380V,415V are availbale;
OPTIONAL
- Quick Change Tool
- Quick Change Die Set Rack;
► DIE SETS WITH HIGH HARDNESS
10 sets dies for hose from 6mm to 51mm, hardness 59-63HRC
