| Brand Name: | FY |
| Model Number: | FY-51xk |
| MOQ: | 1 set |
| Price: | USD$ 2250/2200/2150/2100 |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 300 sets per month |
2 Inch 10 dies New Model Big Power 4 kw Portable Hose Crimping Machine/Hose Crimper
DESCRIPTION
Portable Hydraulic Hose Crimper - New Model
This advanced 2 Inch 6-51mm 10 dies New Model Hose Crimping Matching Dies Big Power 4 kw Working Efficiency Is 500 pieces Per Hour crimping machine is designed for efficiency and power, featuring a robust 4 kW motor. This hose crimping machine accommodates a range of hoses from 2 inches to 6-51mm, making this hose crimping machine versatile for various applications. Equipped with 10 dies, 2 Inch 6-51mm 10 dies New Model Hose Matching Dies Big Power Working Efficiency Is 500 pieces Per Hour ensures precise matching for optimal performance.With a remarkable working efficiency of up to 500 pieces per hour, this tool is ideal for high-demand environments.This hose crimping machine compact design allows for easy portability, making hose crimping machine perfect for on-site use, especially in excavator hose applications. Upgrade your hose crimping capabilities with this reliable and powerful tool.
Our products have been widely used in various industries like engineering machinery,coal mines,chemicals, metallurgy,petroleum,automobile,shipbuilding,aviation and transport.
FY-51XK is a hose crimper for hydraulic high pressure flexible hose range from 1/4 inch to 2 inch one to six stainless steel wire braided or spiraled. It has three different operate mode, to meet customer different need.
MAIN ADVANTAGES
1. Big oil pump, efficient and long life
2. Multifunctional operate panel, easy to change between automatic and semi-auto
3. Pressure can be shown on the panel
4. Foot pedal as standard to make hands free
5. Working light to make crimping work more clear
TECHNICAL DATA
| Model | FY-51XK Hose Crimping Machine |
| Crimping Range | 6-51(mm) |
| Crimping Force | 600(T) |
| Hose Size | 1/4-2(inch) |
| Max. Opening | 30±mm |
| Die Sets | 10 |
|
Maximum Open Diameter |
114MM |
| System Pressure | 31.5(Mpa) |
| Accuracy | 0.01(mm) |
|
Work Efficiency |
500 pcs/h |
| Standard Voltage |
220v/240v/380v/415v(optional) |
| Motor Power | 4(KW) |
| Length | 800(mm) |
| Width | 650(mm) |
| Height | 1230(mm) |
| Weight | 310(KG) |
NOTE
- for non standard die sets;
- Customized die sets are available;
- Special voltage 220V, 240V, 380V,415V are availbale;
OPTIONAL
- Quick Change Tool
- UC control;
► TWO MODE EASY ALTERNATED
Automatic or semi-automatic mode can be choosen
