600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper

name

600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper

Brand Name: FanYing
Model Number: FY-51QY
MOQ: 1 set
Price: Negotiable
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 10000 SETS PER MONTH
Detail Information
Product Description
Detail Information
Place of Origin:
China,Shanghai
Weight:
310KG
System Pressure:
31.5mpa
Material:
Rubber
Name:
Rubber Hose Crimping Machine
Warranty:
1 Year
Crimping Force:
600T
Type:
Crimping Machine
Product Name:
1/4 To 2 Inch Crimping Size 2.5 Inch Inner Hose Diameter 600T Crimping Force Rubber Hose Crimping Machine With 6-51mm Range And 10 Interchangeable Dies With Fast Change Mould Tools
Packaging Details:
STANDARD WOODEN BOX
Supply Ability:
10000 SETS PER MONTH
Highlight:

600T Crimping Force Rubber Hose Crimping Machine

,

6-51mm Crimping Range Hydraulic Hose Crimper

,

10 Interchangeable Dies Hose Crimping Equipment

Product Description
600T Rubber Hose Crimping Machine
Introducing the 600T Rubber Hose Crimping Machine, engineered for high-performance crimping in various hydraulic applications. This advanced machine accommodates crimping sizes from 1/4 to 2 inches with an impressive inner hose diameter capacity of 2.5 inches. With a crimping force of 600 tons, this machine is ideally suited for hydraulic repair shops, automotive service centers, and oil distribution businesses. Equipped with a crimping range of 6mm to 51mm and 10 interchangeable dies with fast change mould tools, this machine ensures efficiency and versatility for all your crimping needs.
Key Features
  • High Crimping Force: 600-ton capacity ensures secure connections for high-pressure hydraulic hoses
  • Versatile Crimping Size: Handles hoses from 1/4 to 2 inches for various applications
  • Large Capacity: Accommodates hoses with 2.5 inches inner diameter for heavy-duty applications
  • Interchangeable Dies: 10 die sets allow quick adaptation to different hose sizes and types
  • Fast Change System: Rapid die swaps reduce downtime and increase productivity
  • Robust Construction: High-quality materials ensure durability in demanding settings
Performance Advantages
  • Enhanced productivity through high crimping force and quick die changes
  • Wide applicability across hydraulic repair, automotive services, and oil applications
  • Cost-effective solution reducing need for additional equipment
  • Essential safety features for secure operation
  • User-friendly design with intuitive controls for all experience levels
600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 0 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 1
Technical Specifications
Crimping Range 6-51 mm
Crimping Force 600 T
Quantity of Dies 10 sets
Accuracy 0.01 mm
System Pressure 31.5 MPa
Motor Power 3 kW
Voltage Options 220V/240V/380V/415V
Work Efficiency 200 pcs/h
Maximum Open Diameter 114 mm
Machine Dimensions 860 * 640 * 1300 mm
Net Weight 310 kg
Warranty 1 Year
Industrial Applications
The FanYing FY-51QY Electric Hydraulic Rubber Hose Crimping Machine serves multiple industrial sectors including automotive, construction, machinery, mining, aviation, railway, chemical, and oil & gas industries. Ideal for crimping hydraulic and pneumatic rubber hoses, fuel hoses, oil pipes, and various industrial rubber hose applications.
Product Customization & Support
Manufactured in Shanghai, China with comprehensive 1-year warranty. Features include 600T crimping force, 6-51mm crimping range, and compact dimensions of 860*640*1300 mm. Complete technical support available 24/7 with trained technicians providing onsite installation, training, maintenance, and repair services.
Frequently Asked Questions
What sizes of hoses can this machine crimp?
The rubber hose crimping machine can handle hoses ranging from 6mm to 51mm, making it suitable for various rubber hose applications.
How does the fast change mould system enhance workflow?
The fast change mould system allows for quick swaps between dies, significantly reducing downtime and enhancing workflow efficiency in busy settings.
What is the maximum crimping force of this machine?
This machine offers an impressive crimping force of 600 tons, capable of securely crimping high-pressure rubber hoses.
Is this machine suitable for heavy-duty applications?
Yes, designed for high crimping force, this machine is ideal for heavy-duty applications in hydraulic and automotive fields.
How durable is the construction of this machine?
Constructed from high-quality materials, the machine is built for longevity and reliability, even with continuous use in demanding environments.
Product Gallery
600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 2 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 3 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 4 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 5 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 6 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 7 600T Crimping Force Rubber Hose Crimping Machine with 6-51mm Range and 10 Interchangeable Dies for Hydraulic Hose Crimper 8
The 2 Inch 600T Rubber Hose Crimping Machine is an essential tool for professionals in the hydraulic and automotive industries. With its high crimping force, versatile design, and user-friendly operation, it boosts productivity and ensures reliable hose management. Invest in this high-performance rubber hose crimping machine to meet your operational demands and achieve outstanding results in your crimping applications!
