3 Inch FY-CBK-120 Super Thiness Model Hydraulic Hose Crimping Machine Black And Blue Color With 6-76mm Crimping Range 165mm Max Opening And 15 Dies 220v/380v Voltage

Name: 3 Inch FY-CBK-120 Super Thiness Model Hydraulic Hose Crimping Machine Black And Blue Color With 6-76mm Crimping Range 165mm Max Opening And 15 Dies 220v/380v Voltage
Brand: Shanghai Fanying Machinery Technology Co., Ltd.
SKU: FY-CBK120
Price: 4850 USD
Availability: InStock

Brand Name:	FY
Model Number:	FY-CBK120
MOQ:	1 set
Price:	USD$ 4850
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,
Supply Ability:	10000 SETS PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Document:

our new catalogue.pdf

Crimping Speed:

10-15s/time

Product Name:

3 Inch Super Thiness Model Hydraulic Hose Crimping Machine Black And Blue Color With 6-76mm Crimping Range 165mm Max Opening And 15 Dies

Packaging Details:

STANDARD WOODEN BOX

Supply Ability:

10000 SETS PER MONTH

Highlight:

3 inch hydraulic hose crimping machine

FY-CBK-120 thin hose crimper

220v/380v hydraulic crimping machine

Product Description

3 Inch FY-CBK-120 Super Thiness Model Hydraulic Hose Crimping Machine Black And Blue Color With 6-76mm Crimping Range 165mm Max Opening And 15 Dies 220v/380v Voltage

Hydraulic Hose Crimping Machine 3 Inch Super Thickness Model with 165mm Opening

Heavy-Duty Hydraulic Hose Crimping Machine for Industrial Hose Assembly

3 Inch Hydraulic Hose Crimping Machine | FY-CBK-120 Super-Thin Model

Meta Title: 3 Inch Hydraulic Hose Crimping Machine | FY-CBK-120
Meta Description: FY-CBK-120 Hydraulic Hose Crimping Machine with a 6–76 mm crimping range, 165 mm maximum opening, 15 dies, and 220V/380V voltage options.

Professional 3 Inch Hydraulic Hose Crimping Machine

The FY-CBK-120 Hydraulic Hose Crimping Machine is a compact and efficient solution for crimping hydraulic hose assemblies up to 3 inches. Designed with a super-thin body structure, this machine helps save valuable workshop space while providing reliable performance for hydraulic hose repair, maintenance, and assembly applications.

With a 6–76 mm crimping range and a 165 mm maximum opening, the FY-CBK-120 can handle a broad selection of hydraulic hoses and fittings. It is suitable for hydraulic repair shops, car repair centers, oil-service companies, hose distributors, and industrial maintenance workshops.

The machine is available in a professional black and blue color combination, making it suitable for modern workshop environments. With 15 interchangeable dies, operators can work with different hose sizes without purchasing multiple crimping machines. The die system also supports flexible hose processing for routine repair and replacement work.

Key Features

3-inch hose crimping capacity for medium- and large-diameter hydraulic hoses.
6–76 mm crimping range for a wide variety of hose assemblies.
165 mm maximum opening for easier fitting and positioning of larger hoses.
Super-thin model design helps reduce floor-space requirements.
Includes 15 interchangeable dies for different hose sizes and applications.
Available in 220V and 380V voltage configurations.
Durable black and blue finish for a professional appearance.
Suitable for hydraulic hose repair, replacement, maintenance, and workshop assembly.
Practical design for hydraulic, automotive, oil, construction, and industrial hose applications.

Product Advantages

The main advantage of this hydraulic hose crimping machine is its combination of a space-saving design and wide working range. The slim body is useful for workshops where floor space is limited, while the 165 mm maximum opening provides convenient access when positioning hose and fittings.

The 15-die configuration gives repair shops greater flexibility when handling different hose diameters. Instead of using separate equipment for every size, one machine can support a variety of common hose service requirements. This can help improve workshop organization, reduce equipment investment, and increase service efficiency.

The FY-CBK-120 is a suitable choice for customers in the USA, Europe, Southeast Asia, and other international markets. Before ordering, buyers should confirm the required voltage, frequency, phase, hose specifications, and local electrical standards.

Technical Specifications

Specification	Details
Crimping Range	6-76 mm (1/4~3")
Quantity of Dies	15 sets
Accuracy	0.01 mm
System Pressure	31.5 mpa
Motor Power	5.5kw/7.5Kw
Voltage	110V/220V/380V/415V 50/60Hz (optional)
Crimping Force	1500 t
Work Efficiency	300 pcs/h
Maximum Open Diameter	165 mm
Machine Dimension	10008001630 mm
Net Weight	1250 kg

Control System Specifications

Specification	Details
Control System	PLC/BUTTON/DIGITAL PANEL
Model	AC Hose Crimping Machine
Crimping Speed	10-15s/time
Crimping Type	One-time Crimping
Output Volume of Pump	10L/16L

Applications

FY Hose Crimping Machine, Model Number FY-CBK120, is a perfect solution for crimping 3 inch hoses from 6-76mm in diameter. It features one-time crimping technology and is widely used for various applications including crimping air, water, fuel, and oil lines, as well as hydraulic hoses that require high pressure to work properly. It is ideal for automotive, industrial, and commercial applications.

Frequently Asked Questions

What maximum hose size can this machine crimp?

The machine supports hose diameters up to 76 mm (3 inches).

What is the benefit of a 165 mm maximum opening?

The 165 mm opening simplifies loading of larger fittings and assemblies, reducing setup time for bulky jobs.

How many dies come with the crimper and can I order more?

The unit includes 15 interchangeable dies. Additional or custom dies are available from the supplier for special fittings or non-standard hose sizes.

Is the control system easy to use for new operators?

Yes - the button-control panel is designed for straightforward operation with minimal training required.

Which voltage should I choose for my region?

The machine is available in 220 V and 380 V configurations. Specify your local supply when ordering to ensure compatibility.

Additional Product Information

Brand Name: FY
Model Number: FY-CBK120
Origin: China
Construction Material: Durable metal
Installation Time: Approximately 2 hours

Support and Services

Our AC Hose Crimping Machine comes with technical support and service for your convenience. Our experts are available to help you with any questions or issues you may have. We provide comprehensive training sessions on product use, along with step-by-step instructions. We also offer a wide range of spare parts and accessories including crimping heads, hose cutters, and more.

Packing and Shipping

The AC Hose Crimping Machine is securely packaged in a wooden box with additional styrofoam cushioning to prevent damage during shipping. All packages are tracked until delivery to ensure safe arrival.

Ready to Enhance Your Operations?

This 3 Inch button-control Black Hydraulic Hose Crimping Machine combines flexibility, durability and operator-friendly controls to meet the needs of hydraulic shops, car repair centers and oil-service operations. Contact your local distributor to configure voltage, die sets and delivery options!
