2 Inch 600 Ton 31.5Mpa Rubber Hose Crimping Machine Higher Model Blue Color 3kw/4kw Motor Button Control Systerm 220v/240v/380v/415v Voltage With 6 To 51mm Crimping Range And 10 Interchangeable Dies

Name: 2 Inch 600 Ton 31.5Mpa Rubber Hose Crimping Machine Higher Model Blue Color 3kw/4kw Motor Button Control Systerm 220v/240v/380v/415v Voltage With 6 To 51mm Crimping Range And 10 Interchangeable Dies
Brand: Shanghai Fanying Machinery Technology Co., Ltd.
SKU: FY-51BY
Price: 1,575.00 USD
Availability: InStock

Brand Name:	FanYing
Model Number:	FY-51BY
MOQ:	1 set
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,
Supply Ability:	10000 SETS PER MONTH

Detail Information

Product Description

Detail Information

Place of Origin:

China,Shanghai

Document:

our new catalogue.pdf

Weight:

310 Kg

System Pressure:

315 Bar

Material:

Rubber/Hose

Name:

Rubber Hose Crimping Machine

Warranty:

1 Year

Crimping Force:

600T/0.6MT

Type:

Crimping Machine/crimper

Product Name:

600T 31.5Mpa Rubber Hose Crimping Machine Higher Model Blue Color 3kw Motor Button Control Systerm 220v/240v/380v/415v Voltage With 6-51mm Crimping Range And 10 Interchangeable Dies

Color:

Blue Or As Client Demand

Packaging Details:

STANDARD WOODEN BOX

Supply Ability:

10000 SETS PER MONTH

Highlight:

2 inch rubber hose crimping machine

600 ton hydraulic crimping machine

31.5Mpa button control crimper

Product Description

2 Inch 600 Ton 31.5Mpa Rubber Hose Crimping Machine Higher Model Blue Color 3kw/4kw Motor Button Control Systerm 220v/240v/380v/415v Voltage With 6
To 51mm Crimping Range And 10 Interchangeable Dies

Rubber Hose Crimping Machine 2 Inch 600T with 3KW Motor and 31.5Mpa Pressure

High-Performance Rubber Hose Crimping Machine for Hydraulic Hose Assembly

2 Inch Rubber Hose Crimping Machine | 600 Ton, 31.5 MPa

Meta Title: Rubber Hose Crimping Machine 6–51 mm | 600 Ton Hydraulic Crimper
Meta Description: Professional Rubber Hose Crimping Machine with 600-ton force, 31.5 MPa pressure, 6–51 mm crimping range, 10 interchangeable dies, and 220V–415V voltage options.

High-Performance Rubber Hose Crimping Machine

The Rubber Hose Crimping Machine is a professional hydraulic solution for assembling, repairing, and replacing rubber hoses used in hydraulic systems, automotive equipment, oil-service applications, construction machinery, and industrial maintenance. With a crimping range of 6–51 mm, this machine is suitable for hose assemblies up to approximately 2 inches, making it a practical choice for hydraulic repair shops, car repair centers, hose suppliers, and oil-service companies.

This higher-model machine provides a powerful 600-ton crimping force and a rated hydraulic pressure of up to 31.5 MPa. The strong hydraulic system supports stable forming of rubber hoses and fittings, helping users achieve secure and consistent hose assemblies when the correct hose, fitting, die, and crimping specifications are selected.

The machine is available with a 3 kW or 4 kW motor, allowing customers to choose a configuration according to their required working capacity and local power conditions. Its convenient button control system makes daily operation straightforward, while the blue exterior provides a professional appearance and added surface protection in demanding workshop environments.

Key Features

2-inch hose crimping capacity for common rubber and hydraulic hose applications.
6–51 mm crimping range for a wide selection of hose sizes.
Powerful 600-ton hydraulic crimping force.
Hydraulic system pressure up to 31.5 MPa.
Available with 3 kW or 4 kW motor options.
Convenient button control system for simple operation.
Includes 10 interchangeable dies for different hose diameters.
Available in 220V, 240V, 380V, and 415V voltage configurations.
Blue painted finish suitable for professional workshops.
Designed for rubber hose repair, maintenance, and hose assembly production.

Product Advantages

The main advantage of this Rubber Hose Crimping Machine is its combination of strong crimping force, flexible tooling, and practical operation. The 10 interchangeable dies allow one machine to process various hose sizes, reducing the need for multiple pieces of equipment and helping workshops save valuable floor space.

The 600-ton hydraulic force is suitable for demanding rubber hose applications, while the 6–51 mm working range covers many common hose assemblies used in automotive repair, hydraulic equipment, oil systems, agriculture, construction, and industrial machinery. The button control system helps operators complete routine crimping tasks efficiently and consistently.

This machine is suitable for customers in the USA, Europe, Southeast Asia, and other international markets. Before ordering, confirm the required voltage, frequency, motor power, hose specifications, die sizes, and local electrical standards.

2 Inch 600 Ton 31.5Mpa Rubber Hose Crimping Machine Higher Model Blue Color 3kw/4kw Motor Button Control Systerm 220v/240v/380v/415v Voltage With 6 To 51mm Crimping Range And 10 Interchangeable Dies

Technical Specifications

Specification	Value
Crimping Range	6-51 mm
Crimping Force	600 T
Quantity of Dies	10 sets
Accuracy	0.01 mm
System Pressure	31.5 MPa
Motor Power	3 kW
Voltage Options	220V/240V/380V/415V
Work Efficiency	200 pcs/h
Maximum Open Diameter	114 mm
Machine Dimensions	860 * 640 * 1300 mm
Net Weight	310 kg
Warranty	1 Year

Operational Advantages

Enhanced Efficiency: Strong crimping force and quick-change dies increase workshop productivity
Cost-Effective Solution: Accommodates multiple hose sizes, reducing equipment investment
User-Friendly Operation: Intuitive design requires minimal training for technicians
Dependable Performance: Heavy-duty construction minimizes operational interruptions
Multi-Industry Application: Suitable for hydraulic repair, automotive service, and oil industries

Industrial Applications

The FanYing FY-51QY Electric Hydraulic Rubber Hose Crimping Machine serves multiple industrial sectors including automotive, construction, machinery, mining, aviation, railway, chemical, and oil & gas industries. Ideal for crimping hydraulic and pneumatic rubber hoses, fuel hoses, oil pipes, and various industrial rubber hose applications.

Product Support & Customization

Manufactured in Shanghai, China with comprehensive 1-year warranty. Complete technical support available 24/7 with trained technicians providing onsite installation, training, maintenance, and repair services.

Frequently Asked Questions

What sizes of hoses can this machine crimp?

The rubber hose crimping machine can handle hoses ranging from 6mm to 51mm, making it suitable for various rubber hose applications.

How does the fast change mould system enhance workflow?

The fast change mould system allows for quick swaps between dies, significantly reducing downtime and enhancing workflow efficiency in busy settings.

What is the maximum crimping force of this machine?

This machine offers an impressive crimping force of 600 tons, capable of securely crimping high-pressure rubber hoses.

Is this machine suitable for heavy-duty applications?

Yes, designed for high crimping force, this machine is ideal for heavy-duty applications in hydraulic and automotive fields.

How durable is the construction of this machine?

Constructed from high-quality materials, the machine is built for longevity and reliability, even with continuous use in demanding environments.

Professional-Grade Performance: The 2 Inch 600T Rubber Hose Crimping Machine is an essential tool for professionals in the hydraulic and automotive industries. With its high crimping force, versatile design, and user-friendly operation, it boosts productivity and ensures reliable hose management. Invest in this high-performance rubber hose crimping machine to meet your operational demands and achieve outstanding results in your crimping applications!
